Details
The Shift S3 is an excellent full suspension performer for Trail riding. With its 1x transmission, the 27.5" Shift S3 offers a wider gearing ratio for easier climbing. Its X6 alloy frame with tapered head tube and 120mm of travel features a simple and efficient single pivot suspension design, which allows for an easy and low-cost maintenance. The Suntour Raidon XC air fork and rear shock suspension package provides 120mm of travel while the new 1x Shimano Deore drivetrain with a Deore 11-46T 10-speed cassette is matched to a Suntour Zeron 30T crankset for a wider gearing choice. Last but not least, efficient stopping is provided by a set of Shimano MT-200 disc brakes complete with 180/160mm rotors.
Features
- Shift S X6 Aluminum single pivot frame, 120mm travel w/ 9mm Q/R rear dropouts
- Suntour Raidon-R rear shock
- Suntour Raidon-XC-LO-R fork, 120mm travel, air spring w/ lockout
- Suntour Zeron 1x Boost crankset, 30T
- New Deore RD-M5120 10-spd Shadow + rear derailleur
- New Deore M4100 10-spd, 11-46T cassette + shifter
- Shimano HB-TX505 hubs
- Shimano MT-200 Hydraulic disc brakeset
- Pivit aluminum cockpit with 0 Deg. Trail stem
Specs
Frame | Shift S X6 Aluminum series dual suspended Single Pivot frame | 27.5"x120mm travel | Tapered 1.5" head tube | 73mm threaded BSA | Enduro bearings | 9mm Q/R rear |
---|---|
Fork | SR Suntour Raidon-XC-LO-R-27.5 | 1.5" Tapered Aluminum steer tube | 120mm travel | Air spring | Hydraulic lockout |
Headset | FPD DOZER-1160A-2 w/ 1.5" ACB bottom | For 44/56mm head tube | 8mm Top Cone |
Rear Shock | Suntour Raidon R | 190X51 |
Rims/Wheels | Pivit XD-260 Disc | 27.5" x 32h aluminum double wall |
Hubs | New Shimano TX-505 aluminum | Center Lock Discs | cassette 32h |
Tires | Kenda Honey Badger 27.5x2.20" | 30tpi |
Crankset | Suntour Zeron 1X AX-S-30 | 30T Steel Zig-Zag Chainring |
Bottom Bracket | Suntour BB-BKA008-C | 73mm | sealed cartridge |
Chain | KMC X10 NP/GY | Missing Link |
Rear Derailleur | New Shimano Deore RD-M5120 | 10-spd | Shadow Plus |
Cassette/Rear Cogs | New Shimano Deore CS-M4100-10 | 10-spd | 11-46T |
Shifters | New Shimano Deore SL-M4100-R 10-spd |
Handlebars | Pivit aluminum 20mm riser bar 31.8mm | 700 / 720mm | 9 Deg. sweep |
Tape/Grips | WTB Weirwolf |
Stem | Pivit alloy Trail 0 Deg. | 4 bolts | Ext.: 60mm |
Brake Levers | Shimano BL-MT200 hydraulic |
Brakes | Shimano hydraulic BR-MT200 | 180/160mm Center Lock rotors |
Pedals | Sold separately |
Saddle | WTB Volt Sport w/ color accents |
Seat Post | Pivit alloy micro adjust 31.6mm | 350mm |
Accessories & Extras | Frame bearings by Enduro USA |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN |
---|---|---|
Vivid Blue / Small | 691840114127 | 11412 |
Black/Neon / Small | 691840114028 | 11402 |
